Description
Water Sampling & Monitoring USV
SE40 water quality sampling unmanned ship is an intelligent unmanned ship device used to replace manual water environment monitoring and water quality sampling in lakes, reservoirs, river basins, nearshore waters, and other water areas.
Fast Switch Between Missions
It can carry multi instruments such as water probes for water quality monitoring, echo sounder for bathymetry survey, and ADCP for river discharge measurement.
Automatic mission planning
You can pre-program the sampling and monitoring mission with just a few drags and clicks on the base station computer. SE40 carrying instruments can conduct sampling and monitoring autonomously and send back real-time data.
You can also drive SE40 by a remote controller to reach some difficult corners.
Higher speed & tangling free
The innovative water jet thruster brings SE40 USV to a top speed 5m/s and effectively avoid being entangled by water plants or debris.
Stable sailing
The trimaran hull design dramatically improves stability when sailing at high speed.
Intelligent collision avoidance
Equipped with radar sensors, SE40 USV can detect obstacles and avoid collision within 50 meters.
In manual mode, you can observe the water environment via real-time video to improve navigation safety.
Specification
| Hull Material | Carbon fiber |
| Dimension | (L)165 cm *(W)70 cm |
| Weight | 44 kg（with batteries） |
| Payload | 25 kg |
| Draft | 15 cm |
| Propulsion | Electric water-jet propeller |
| Communication Range | Data telemetry: 2 km Remote Control: 1 km |
| Max. Speed | 10 knots (5 m/s) |
| Battery Life | 8 hrs @ 3kn |
